3D Railing cable

3DMD Railings are archicad object tools.
You can simple draw a 3d polyline both 2d and 3d window. You can create curved and sloped path. There are many parameters for post, panel, cable, handrail; you can create you own rail. An option for list allow you to have the railing straightened in the schedule also with quantities for each elements of the railing. You can quickly manage in 2d/3d windows the position and visibility of posts and cables/panels.

Compatible with ArchiCAD 16 or higher.

Options:

• Editable railing as a 3d Polyline
• Presets railing type
• Presets position and visibility of posts and cables/panels
• Wall follow the railing with a sill and foundation.
• Position of the railing: left, right and center
• Different post type
• Different holders type and position
• Full editable posts position and visibility
• Full editable cable/panel visibility
• Position of the cable/panel: left, right and center
• Texture follow the slope of the wall
• Schedule with auto railing straightened
• Quantities
